Product introduction

Super The viper SL8300-UV adjustable-light beam UV LED Flashlight

Additional Information:

Tel: (852) 6740 3030; 0086-755-82153693
Fax: 0086-755-82483923
E-mail: info@sunlonge.com, sunlonge@gmail.com

Super The viper SL8300-UV adjustable-light beam UV LED Flashlight

SPECIFICATIONS:

Model: Super The viper SL8300-UV adjustable-light beam UV LED Flashlight

 (Abbreviation The viper SL8300-UV)

Peak-Wavelength:365-370NM;

UV Intensity: 1000-45000UW/cm2 at 15inch(380mm) -See the list;Low visible light emiss ion:less than 2 foot-candles (22 lux)

Number of UV LEDs: 1 x 5W 365NM UV LED with lens, average LED life is 30,000 hours

Power supply: 3.7V 4800 Mah  26650  lithium battery;

Operating Time: 4 hours (continuous)

Irradiated  Area in 38cm Distance:  Ø 100-250mm-See the list.

Stability of UV Intensity: > 90%

Product Size: 216*46mm  ;  WEIGHT :328 g without  accessories

Super The viper SL8300-UV Flashlight can adjustable-light beam  from spotlight to floodlight ,so UV Intensity:1000-45000UW/cm2 at 15inch(380mm)

Radiation cone XL (Ø 250 mm): 20000μW/cm2

Radiation cone L (Ø 150 mm): 35000 μW/cm2

Radiation cone M (Ø 100 mm): 45000 μW/cm2

Adjustable-light beam UV LED Flashlight

SL8300 Series:SL8300-Hight VersionSL8300–Standard Version;SL8300-Aerospace RRES90061;

Abbreviation:SL8300-H,SL8300-S;SL8300-AR (We master the core technology, We can adjust the UV intensity  according to customer requirements)

Model

SL8300-Aerospace RRES90061

SL8300-Standard Version

SL8300-Hight Version

Number of UV LEDs

1 x 5W 365NM UV LED,Optical lens + filter

1 x 5W 365NM UV LED,Optical lens + filter

1 x 5W 365NM UV LED,Optical lens

UV Intensity at 15inch(380mm)

3500/cm2

(1000-3500uw/cm2)

25000uw/cm2

(1000-25000uw/cm2)

45000uw/cm2

(1000-45000uw/cm2)

Visible light emission

< 0.5 FC(5 lux)
 with white light filters Meets ASTM E3022 and  RRES 90061

< 2 FC(20 lux)

 with black light filters

No  filters

Irradiated Area in 38cm Distance

210mm(Diameter)

100-210mm(Diameter)

100-210mm(Diameter)

Power supply

Polymer battery pack DC

The Same

The Same

Suitable for industry

All Aeronautics NDT

Except Aeronautics NDT

Except Aeronautics NDT

Attention to:

SL8300-Aerospace RRES90061   Meets Rolls-Royce RRES 90061 Requirements,

ASTM E1417, ASTM E1444, ASTM E 709, ASTM E2297, ASTM E3022 compliant

FEATURES:

Super The viper SL8300-UV adjustable-light beam UV LED Flashlight from spotlight to floodlight

1. Super The viper SL8300-UV adjustable-light beam UV LED Flashlight provides maximum UV-A performance immediately after switch-on and is especially suited for quick inspections or checks of poorly accessible areas.

2. The high spotlight radiation intensity of the Super The viper SL8300-UV,  a high fluorescence stimulation can be achieved – this way, even minor  so high that even low luminance traces are clearly visible even in daylight.

3. In contrast to conventional UV torches, Super The viper SL8300-UV can not only be used in spotlight mode: An integrated focus ring enables the infinitely variable regulation of the UV-A radiation cone from spotlight to floodlight. This variable focal length adjustment allows a very wide range of applications of Super The viper SL8300-UV .

4. Whether spot light with maximum fluorescence excitation or flood light for a quick examination of larger areas – with just a twist of the focus ring of this ultra compact UV-A hand lamp you always have the optimum light intensity for each task.

5.Whether for leak detection in buildings, some areas of forensics, or non-destructive testing of materials in the industry – the rapidly deployable Super The viper SL8300-UV the user a high degree of flexibility .

STANDARD PACKAGE INCLUDING:

Super The viper SL8300-UV Flashlight, Charger, carry case; Spare UV Filter Glasses;

Application:

Penetration testing, fluorescence detection, Biopolymers, fluorescence observation,

Refrigerant leak detection, Engine oil leak detection;Criminal Investigation: fingerprints, blood observed,

Fluorescence observation of ore, Detection of oil cleaning

Main purposes:

Fluorescence detection: iron and steel, non-ferrous metals, automobiles, aircraft, fluorescent penetrant  inspection, fluorescent magnetic particle inspection,

Pollution check: electronic components, boards, dust inspection, LCD panel, checked into the clean room,

Leak Check: hydraulic machines, sump, pipe and other oil spill inspection, leak detection using fluorescent agents,

Degreasing cleaning validation: the food industry, kitchen, cooking utensils, tableware degreasing cleaning
